JMAG is simulation software for electric device design and development.

It accurately models the complex electromagnetic phenomena in a wide range of equitment.

MAIN FUNCTION

JMAG

Linear Motor:

JMAG can be used to model linear electric machines.

Induction heating:

JMAG accurately simulates and visualizes the intricate changes inherent in induction heating phenomena.
Eddy current flowing through the surface can be obtained with high accuracy, allowing for the generation of a high-quality skin mesh in a work piece.
Detailed thermal management can be achieved by showing a visualization of the flow of eddy current.

'Power transformer:

Large transformers present unique challenges both in design and construction.
JMAG uses a thin shell mesh that can deal with large aspect ratio variations in this type of problem.
Analyzing complex phenomena allows you to create designs you can trust.

Solenoid:

JMAG can optimize the design of a solenoid to maximize the forece while minimizing the volume.
JMAG can create a high fidelity solenoid model that can be exported to a control/ circuit simulation program.
By using a precise plant model (JMAG_RT model), you can now apply a more realistic excitation to your circuit.
